PTP Blister Strapping Machine

0 + Pieces sold in the past 30 days

Specially made for linking after PTP blister packaging machine. The machine stacks and count blister packs to the preset number, and then automatically tightens them with PE film.

DESCRIPTION

Product features

Developed to meet renowned pharmacy brands’ requests, the model made with high tech electronic CAM and Japanese components, and gained considerable favor from the industry.
Built with European specification. Compact design for great saving production line space.
The front end is connected to the PTP blister machine, and the back to the cartoning machine, or check weighing machine for automatic production.
Optional equipment includes CCD inspection, defect rejecting systems, and various label printer devices (hot stamping, inkjet, thermal transfer, laser engraving.)

System Features

By colorful touch panel and PLC control system
Welding temperature uses PID temperature control module to join stable and beautiful interface.
The tighten speed can reach 20 stacks per minute.
The front end is connected to the PTP blister machine, and the back end can be connected to the cartooning machine for automatic production line.

Specification

Model	PTP blister strapping machine
Stacking speed	200 pcs per minute
Strapping speed	25 packs per minute
Finished pack dimension	15～120mm (H); 65~120mm (L); 35~85 (W)
PE film roll outer diameter	Ø200mm
PE film roll inner core diameter	Ø75mm(3″”)
Machine Dimension	830mm (L) ×1850mm (W) ×1920mm (H)
Power	AC 220V (Single phase), 3kW
Compressed Air Supply	5 kg / cm²
