Engine Barcode Labeler

0 + Pieces sold in the past 30 days

Equipped with an industrial-grade barcode printer, powerful functions and fast printing speed, labels can be printed and applied, and text barcode graphics can be printed. Labeling can be done on unmanned production lines by connecting to the database.

DESCRIPTION

Features

The cylinder drive of the label applicator head is stable and reliable, and a rotating mechanism is available for an option to different flat surface labeling applications.
Vacuum applies labels, add vacuum detection to ensure successful labeling application.
Can be connected to the computer database for labeling on the unmanned production line.
Standardized and modular design for easy maintenance.
Color touch panel and PLC control system. Easy to learn and operate.

Optional Accessories

Available for corner mechanism to complete the labeling and folding the label at the same time.
Can be connected to upstream and downstream equipment such as weight checker, barcode readers, etc., to transmit and print real-time data.

Specification

Model	Engine Barcode Labeler
Labeler Line Speed	20Box/min
Accuracy	±2mm
Label Width	M(100mm)/L(140mm)
Printing Device	Industrial Barcode Printer
Label Roll	300mm
Machine Dimension	3300mm(L) × 1550mm(W) × 1920mm(H)
Power	AC 110V/220V 50/60Hz Single Phase; 1kW
